Feature:

1. Compliance with EU Machinery Directive 2006/42/CE certification.

2. Electrical drive and chain balance system.

3. Save land area and take full use of the underground space.

4. Each layer is independent, you can stop or pick up the car directly without moving the car on other layers.

5. Galvanized wave board platform, cold bending, strong and humidity resistance.

6. Four pillars have anti -pendant to ensure safety.

7.  Remote switch box with keys/push button for easy operation.

8. Flexible design can be designed according to customer requirements, which is suitable for residential and commercial purposes.

9. Before the lifting platform, the electronic sensor confirmed that no one or object was.







Specifications:

Product Parameters

Model No.

PJS

Lifting Capacity

2000 kg

Lifting Height

1800mm

Vertical Speed

2 - 3 M/Min

Lock Release

Electric Unlock

External Dimension

5440 x 3000 x 2450

mm

Drive Mode

Motor + Chain

Vehicle Size

5100 x 1950 x 1800

mm

Parking Mode

1 underground, 1 on the ground

Parking Space

2

Rise/Drop Time

70 S / 60 S

Power Supply /

Motor Capacity



220V / 380V, 50Hz / 60Hz, 1Ph / 3Ph,

3.7Kw

220V / 380V, 50Hz /

60Hz,

1Ph / 3Ph, 5.5Kw


Drawing
